1-3. Special Tools
1-4. Serial Number Location
On the spur base unit (visible at the front left when the scanning unit is opened).
Name Tool No. Application Remarks
FLOIL KG-107A QY9-0057-000
To the sliding portions of the carriage rail and main
chassis.
In common with the
S520.
ELECTRICITY GREASE IF-20 CK-8006-000 To the LF earth spring sliding portions.
MOLYKOTE PG641 CK-0562 To the PG - AP arm lever sliding portions.
In common with the
S520.
<1. MAINTENANCE>
