During the journey
2999828 - 05/18 - EHG-0012-00EN
29
4
4.5 ISOFIX child safety seat mounting system
Fig. 7 ISOFIX child safety seat
mounting system
If the vehicle is equipped with the ISOFIX child safety seat mounting system,
the vehicle seats suitable for it are marked with the ISOFIX symbol. These
vehicle seats have retaining clips (Fig. 7,1). Use child restraint system suita-
ble for ISOFIX. The child restraint systems possess connectors which are
latched to the retaining brackets of the vehicle seat.
The bench with the special equipment ISOFIX child safety seat mounting
system is suitable for child seats with ISOFIX system, which are specially
authorised for this vehicle type according to the standard ECE-R 44.
Child restraint systems of the groups 0, 0+, and 1 with ISOFIX child safety
seat mounting system can be fastened at the ISOFIX anchorage points on
the bench.
Push the connectors of the child seat into the ISOFIX anchorage points
until they engage audibly.
By pulling the child seat, check whether both sides have engaged cor-
rectly.
Also observe the instruction manual of the child restraint system manu-
facturer.
4.6 Driver's seat and front passenger's seat
Before commencing the journey, rotate all swivel seats in the direction
of travel and lock in position.
The seats must remain fixed in position during the journey and are not
to be rotated.
The driver's seat and the front passenger's seat are part of the base vehicle.
The adjustment of the seats is described in the operating manual of the
base vehicle.
4.7 Headrests
Before commencing the journey, adjust the headrests so that the back of the
head is supported at approximately ear height.
Fastening a child seat
