Living
2999828 - 05/18 - EHG-0012-00EN
39
6
Depending on the weather, close the skylights far enough to prevent
moisture from entering.
Do not climb on the skylights.
Before commencing the journey, close the skylights.
Before commencing the journey, check that the skylights are closed and
locked.
When leaving the vehicle, always close the skylights.
The upholstery will fade over time, if it is exposed to sunlight. If the tem-
perature within the vehicle rises rapidly as well, the colour will change at
an accelerated rate.
Therefore, we recommend closing the shades on the skylights of the
parked vehicle by 2/3 when there is strong sunlight.
6.5.1 Skylight with snap latch
Fig. 16 Skylight with snap latch
The skylight can be pushed upwards either from one side or from both
sides.
Pull on the handle (Fig. 16,3).
Fold insect screen (Fig. 16,4) downward.
Push the snap latch (Fig. 16,1) towards the inside of the skylight. At the
same time use the handle (Fig. 16,2) to press the skylight upwards.
Swing insect screen (Fig. 16,4) upwards until it latches in place.
Pull on the handle (Fig. 16,3).
Fold insect screen (Fig. 16,4) downward.
Using both handles (Fig. 16,2), pull down the skylight with force until the
two snap latches (Fig. 16,1) lock into place.
Swing insect screen (Fig. 16,4) upwards until it latches in place.
Opening:
Closing:
