Care
2999828 - 05/18 - EHG-0012-00EN
99
11
11.1.5 Underbody
The underbody of the vehicle is partly coated with an age-resistant under-
body protection. Should the underbody protection be damaged, repair imme-
diately. Do not treat areas coated with underbody protection with spray oil.
Only use products approved by the manufacturer. Our authorised deal-
ers and service centres will be happy to advise you.
11.1.6 Cleaning the entrance step
The entrance step may only be moved by hand when the drive rods
have been released.
If necessary, the entrance step can be removed completely for cleaning.
Fig. 85 Drive rod (entrance step) Fig. 86 End stop (entrance step)
Fully extend the entrance step.
On the transformer/rectifier, switch off the battery cut-off switch.
On the bottom of the entrance step, pull off both locking clips (Fig. 85,2)
on the drive rods (Fig. 85,1).
Release both drive rods from the retaining bolts.
Unscrew one screw (Fig. 86,1) on each side of the entrance step. Such,
the end stop of the entrance step is separated.
Pull entrance step outwards by hand, out of the guide.
Dust entrance step off with a dry brush or suck dust away with a vacuum
cleaner. Do not use any water nor a high-pressure cleaner.
Install the entrance step again by proceeding conveniently in reverse
order.
