Capron Sunlight A68 2018 User Manual

Living
50 2999828 - 05/18 - EHG-0012-00EN
6
6.11 Converting seating group for sleeping
Fig. 40 Removable board on the
right-hand bedding box
 Push both seats in the driver's cabin fully forwards.
 Convert the table to a bed foundation (see section 6.6.1).
 Remove additional removable board (Fig. 40,2) from the right-hand bed-
ding box in the rear.
 Fold footrest (Fig. 40,1) out on the removable board.
Fig. 41 During conversion Fig. 42 After conversion
 Hook removable board (Fig. 41,1) in on the side of the bench and place
it on the table.
 Place additional cushion (Fig. 42,1) on the lowered table as shown in
the image.
