Living
2999828 - 05/18 - EHG-0012-00EN
49
6
6.10.3 Bunk bed in the rear
Only use the bunk bed in the rear with fall out protection.
The bunk bed consists of 2 removable bed bases, 4 cushions, a fall out pro-
tection, and an attachable ladder.
The maximum permitted load on each bed base of the bunk bed is 100 kg.
Fig. 37 Bunk bed Fig. 38 Bunk bed with attached lad-
der
A ladder (Fig. 38) can be attached to the bunk bed to make the access to
the bunk bed easier.
Fig. 39 Bunk bed, converted into
seating group
The bunk bed can be converted into a seating group (Fig. 39). In order to do
this, set the bed bases down on the clamping rails upside down, and use the
cushions of the rear bed as backrests.
