Electrical system
2999828 - 05/18 - EHG-0012-00EN
69
8
LED indicator Tank fill level
Level indicator
All LEDs light up Full tank
3 LEDs light up Tank approx. 3/4 full
2 LEDs light up Tank approx. 1/2 full
1 LED lights up Tank approx. 1/4 full
Bottom LED flashes Tank empty
Further information can be obtained in the manufacturer's instruction
manual.
8.6 230 V power supply
Only allow qualified personnel to work on the electrical system.
Have the vehicle's electrical system checked by a qualified electrician
at least once every 3 years. If the vehicle is used frequently, an an-
nual check is recommended.
The 230 V power supply provides electricity for:
sockets with earth contact for appliances with maximum 10 A
transformer/rectifier
The electrical appliances connected to the 12 V power supply of the living
area are supplied with voltage by the living area battery.
Connect the vehicle to an external 230 V power supply system as often as
possible. The charger module in the transformer/rectifier automatically
charges the living area battery. In addition to this, the starter battery is
charged with a float charge.
8.6.1 230 V connection (CEE socket outlet)
Overvoltage can damage connected devices. Overvoltage can be
caused by lightning, irregular voltage sources (e.g. petrol-operated gen-
erators) or power connections on ferries for example.
The connecting cable, the plug connectors at the point of supply and the
plug connector to the vehicle must comply with IEC 60309. The stand-
ard designation for the plug connectors is "CEE blue".
Use H07RN-F rubber sheathed cable with a minimum cable cross-sec-
tion of 2.5 mm² and a maximum length of 25 m.
Earth contact connectors (safety) are not permitted. The interconnection
of CEE/safety adapters is also prohibited.
Requirements concerning
the 230
