Cardinal 212 Series User Manual

212/212X Installation & Technical
8200-M639-O1 Rev D 09/14
Page 1
1. OVERVIEW
1.1 Specifications
Power Requirements:
12VDC (10.5-14.4VDC) using an external
battery or an optional 12VDC @ 1A, AC
Power Adapter (Cardinal part number AGPS)
Enclosure Type:
Thermoplastic
Enclosure Size:
9.0" H x 11.2” W x 4.3” D
(229mm H x 284mm W x 109mm D)
Shipping Weight:
12 lbs / 5.4 kg
Operating Environment:
-4 to 158 ºF (-20 to +70 ºC)
Display:
212 (212-1S, 212-4S)
212X (212X-1S, 212X-4S)
12 digit, 15 segment, 0.8" high backlit,
transflective LCD, 12 annunciators
6 digit, 15 segment, 2" high backlit,
transflective LCD, 18 annunciators
Transducer Excitation:
9.4 VDC
Signal Input Range:
1.0 mV min. to 31 mV max. (with dead load
boost)
Number of Load Cells:
8 each, 350 OHM minimum resistance
Division Value:
0 to 99
Sensitivity:
0.15uV/e
Scale Divisions:
100 to 240,000
Internal Resolution:
1 part in 16,777,216
Tare Capacity:
Scale Capacity
Sample Rate:
1 to 100 samples per second, selectable
Auto Zero Range:
0.5 or 1 through 9 divisions
Weighing Units:
Pounds/Kilograms
Keypad:
Color coded Membrane type, 24 keys
Standard I/O:
(1) bi-directional RS232
(1) output only 20mA
