212/212X Installation & Technical
8200-M639-O1 Rev D 09/14
1.3 Key Descriptions
The Model 212/212X is equipped with a 24-key keypad. The keypad is
used to enter commands and data into the instrument. This section
describes each key along with its normal function. It is helpful to refer to
the actual instrument while reading this section.
DO NOT operate the keypad with pointed objects (pencils,
pens, etc). Damage to keypad resulting from this practice is
NOT covered under warranty
Figure No. 3
The ON/OFF key is used to turn the indicator on and
off.
Press the ON/OFF key when the indicator is off to
turn the indicator ON. The 212/212X will show
the model number and software version and then
change to the weight display.
If the indicator is already on, press the ON/OFF
key. The display will show OFF and turn the
indicator OFF.
