APPENDIX B
SETUP PARAMETERS FOR MODELS 708-AC AND 708-ACD
708-AC
The 708-AC is a version of the standard Model 708 Weight Indicating Instrument that allows a value
of 1 to 99 to be selected for INTERVAL (division value). NOTE: All other setup parameters are the
same as the standard 708.
[int] = (1 to 99)
708-ACD
The 708-ACD is a version of the standard Model 708 Weight Indicating Instrument that incorporates
the automatic selection of certain SETUP parameters. These settings are established on power-up
and cannot be changed afterwards. In addition, these automatically selected parameters are not
displayed during SETUP or SETUP REVIEW operations. These setup parameters and the fixed
values are as follows:
Power Up Zero = NO
Auto Shutoff = 0
Sleep = 0
Preset Weight Comparators = NO
Checkweigher = OFF
Push Button Tare = NO
Printer Continuous Output = YES
400 Series Format (400?) = NO
Data Format Termination = Set by 200 series format
(PC = YES and 400? = NO)
End of Print Line Feeds = 0
Inhibit Serial Data = YES
The 708-ACD also sets limits on the SAMPLE RATE and FILTER selections. The value selected for
SAMPLE RATE [Sr=] must be between 8 and 12 samples (greater than or equal to 8
OR less than
or equal to 12). The value selected for FILTER [FLt=] is limited to 0 or 3 (no filtering
OR custom
filtering).
Sample Rate = 8 - 12
Filter = 0 or 3
INVERT SETUP PARAMETER
Both the 708-AC and 708-ACD have an additional setup parameter after the ISNd (Inhibit Serial
Data) prompt. The additional parameter is INVERT with Nurt displayed for the prompt. INVERT,
when on, makes the indicator weight
backwards . For example, an add-mix hopper will actually have
the maximum weight on the load cell when the hopper is empty due to the load cell signal increas-
ing as the mix leaves the hopper. Calibration steps remain the same and operation of the scale, to
the operator, appears normal. However, as the mix leaves the hopper, the weight decreases.
INVERT
press the ENTER key to view the current setting. If YES
is displayed, the feature has been enables, while a NO
indicates the feature is disabled. Press the 1 key to
change the setting to YES or the 0 key to change it to
NO. Then press the ENTER key to save the setting.
Nurt
