12
CrLF
EoP=
iSnd
PC=
PRINTER CONTINUOUS OUTPUT
press the ENTER key to view the current setting for this
feature. If a YES is displayed, the feature has been
enabled and the 708 emit a continuous output of weight
data at the serial I/O connector. If a NO is displayed the
data will only be transmitted when the PRINT key is
pressed or on receipt of an ENQ command from an external device. The 1 key
may be pressed to change the display to YES or the 0 key to change the display
to NO. Once the correct response is shown, press the ENTER key to save the
setting. The YES display will show 400?, which asks if the continuous output is
to be in a format compatible with the Cardinal 400 Series Remote Display. Press
the ENTER key to display the setting. A YES display means that data
compatible with this remote display and with a computer will be transmitted; a
NO display means that the data will be in a format compatible with the Cardinal
200 series remote display. The 1 key may be pressed to change the setting to
YES or the 0 key to change it to NO. Once the proper response is displayed,
press the ENTER key to save it.
DATA FORMAT TERMINATION
data transmitted from the serial I/O port can be
terminated with a single carriage return and either no
line feed or a single line feed command. Press the
ENTER key to view the current setting. An ON display
means the data will be terminated with a carriage return
AND a line feed while an OFF display means the data will be terminated with a
single carriage return only. Press the 1 key to change the setting to ON or the 0
key to change it to OFF. Once the proper setting is displayed, press the ENTER
key to save it.
END-OF-PRINT LINE FEEDS
at the end of a data transmission to a printer, the 708
can transmit a pre-selected number of line feed
commands to space the paper in the printer to the
desired position for withdrawal or for the next print. Press
the ENTER key to view the setting (0 to 66). If the setting
shown is acceptable, press the ENTER key to save it,
otherwise, use the numeric keys to enter the desired
value and press the ENTER key to save it.
INHIBIT SERIAL DATA
Yes/No to inhibit sending serial data during input. If yes,
all serial output will stop while weight is not being
displayed (i.e. while inputting tare and presets).
SETUP AND CALIBRATION COMPLETED
at the end of the setup and calibration the 708 will automatically return to normal
operation. Press the OFF key to turn off the 708 and replace the end caps on the
desktop model or close the front panel and tighten the retaining screws on the
NEMA 4X model. If the indicator is to be used in a commercial application a lead
security seal must be applied to prevent access to the calibration switch.
FINE SPAN ADJUSTMENT
with power applied and weight displayed, press and hold the calibration push
button switch, then press the 1 key to increase the span setting or the 0 key to
decrease it. NOTE: The Fine Span Adjustment must be performed only in the
base weight units the indicator was calibrated in. Using the Fine Span Adjustment
in converted weight units will result in weight errors when returning to the base
weight unit. For eample, if the indicator was calibrated in pounds DO NOT
attempt to fine span in the kilograms mode or vice versa.
