PRESET WEIGHT COMPARTATORS
press the ENTER key to display the current status for the
preset weight comparator feature. If YES is displayed, the
two preset weight comparators are enabled while if NO is
displayed the preset weight comparators are turned off.
Press the 1 key to change the setting to YES or the 0 key
to change the setting to NO then press the ENTER key to save the setting. If
the YES setting was selected, the display will show Und1 for the operating
mode of preset number 1. Press the ENTER key to view the current setting. If
ON is displayed, it means that the output associated with preset number 1 is
ON when the displayed weight is less than the preset value for the number 1
preset while if OFF is displayed, the output associated with preset number 1 is
ON when the displayed weight is equal to or greater than the preset value for
the number 1 preset. To change the setting, press the 1 key for ON or the 0 key
for OFF, then press the ENTER key to save the setting. The display will then
show Und2 for the operating mode of preset number 2. Use the same procedure
as used for preset number 1 to view and change the operational setting for this
preset weight comparator. Press the ENTER key to save the settings.
CHECKWEIGHER (if PrS=no)
if the YES setting was selected, the display will show
UndU for the operating mode the UNDER output. Press
the ENTER key to view the current setting. If OFF is
displayed, it means that the output associated with the
under annunciator is on when the under annunciator is
on. If ON is displayed, the output associated with the UNDER annunciator is off
when the under annunciator is on. To change the setting, press the 1 key for
ON and the 0 key for OFF, then press the ENTER key to save the setting. The
display will then show UndA for the operating mode of the ACCEPT output.
Use the same procedure as used for UNDER output to view and change the
operational setting of the ACCEPT output to the same as the UNDER output.
Press the ENTER key to save the settings. The display will then show Undo for
the operating mode of the OVER output. Use the same procedure as used for
UNDER output to view and change the operation settings of the OVER output
to the same as the UNDER output. All three settings must be the same. Press
the ENTER key to save the settings.
PUSH BUTTON TARE
press the ENTER key to view the current setting for this
feature. If a YES is displayed, the feature has been
enabled; a NO indicates the feature is disabled. Press
the 1 key to change the setting to YES or the 0 key to
change it to NO then press the ENTER key to save the
setting. If selected, pressing the TARE key will enter the current gross weight as
the new tare weight and automatically enter the net weight display mode.
BAUD RATE SELECTION
press the ENTER key to show the current setting for the
baud rate for the serial I/O connector. If acceptable, press
the ENTER key to save it, otherwise, enter a two digit
number corresponding to the desired baud rate and
press the ENTER key to save it. The numbers
corresponding to different baud rates are:
12 = 1200 24 = 2400 48 = 4800 96 = 9600 19 = 19200
bAUd
PrS=
CH=
Pbt=
