General Overview
CS 9300C User Guide (SM750)_Ed 01 2–5
Laser Locations
Figure 2-4 illustrates the location of the lasers of the CS 9300C.
Figure 2–4 CS 9300C System Laser Positions
1 3D central positioning laser beam
2 Mid-sagittal positioning laser beam
3 Horizontal positioning laser beam
4 3D Field of View (FoV) positioning laser beam
5 Cephalometric Frankfurt positioning laser beam
3
4
2
1
B
A
A
3
4
1
2
1
2
5
5
B
