Carestream CS 9300C - Mobile Components

General Overview
2–2 CS 9300C OVERVIEW
Mobile Components
Figure 2-1 illustrates the up and down movement of the CS 9300C mobile component
and the 360° rotation of the rotative arm.
Figure 2–1 CS 9300C Mobile Components
