Carestream CS 9300C - Accessing the Cephalometric Acquisition Interface

Starting the Imaging Software
CS 9300C User Guide (SM750)_Ed 01 4–3
1. In the Patient window, from the toolbar, click
OR
From the menu bar, select Patient > New.
2. Enter the required patient information. The Last name, the First name and the Date
of birth fields are required.
3. From the menu bar, select Picture > Insert Picture to add a *.tif or *.bmp picture of
the patient to the record. Select the picture from your directory and click Open.
4. Click OK to save. The patient record is automatically assigned a 7-digit number
starting with a letter (for example, M0000001).
5. Click to access the Imaging window.
6. Select an image acquisition.
Accessing the Cephalometric Acquisition Interface
To access the Acquisition interface, follow these steps:
1. In the Imaging window, from the toolbar, click to access the Cephalometric
Acquisition interface.
2. Prepare the acquisition parameters and launch an acquisition.
