Carimali BlueDot - Additional Units; Machine IDENTIFICATION

2.10
2.4 ADDITIONAL UNITS
FRIDGE (DIGITAL T°) HOT & COLD
Capacity 4,0 l 4,0 l
Voltage 220/230V
Frequency 50/60 Hz
Net Weight
(empty)
14 Kg 17 Kg
Dimensions:
Width
Length
Height
225 mm
462 mm
420 mm
225 mm
462 mm
453 mm
ATTENTION
Refer to the specic label of the additional unit of yours to verify
the correspondence of data.
2.5 MACHINE IDENTIFICATION
TYPE:
MODEL:
Bluedot
220-240V 1~ 50/60Hz
1700 W
1,3MPa (13bar)
.
.
min.0,10MPa / max 0,60MPa
BDS - 1211112 s/n XX123456
CARIMALI S.p.A. - www.carimali.com
Via Industriale, 1 - 24040 Chignolo d’Isola - ITALY
INPUT:
NOMINAL POWER:
COFFEE BOILER PRESS:
.
.
INLET WATER PRESS.
MADE IN ITALY
11/2015
NOTE
Always install the
feet supplied by CA-
RIMALI to the addi-
tional unit.
Fridge (digital T°)
Code AC018
Hot & Cold
Code AC019
