Carimali BlueDot - Grinder Unit Disassembly

4.34
Push the locking ap of the container to-
wards the inner part of the machine, to un-
lock the container.
The grinder can be cleaned by aspirating
the coffee residues through the hole on the
shelf top.
Remove the coffee container upwards to
switch the grinder on.
Remove the dispensing spout of the ground
coffee.
4.10.3 Grinder unit disassembly
NOTE
Carry out this procedure only in case of
total replacement of the grinder or grinder
pack.
Required tools:
● Phillips screwdriver
Cleaning hole
Dispensing spout
