4.10 GRINDER UNIT
4.10.1 Grinder unit adjustment
Open the upper front door.
Slightly press the xing aps to release the
coffee conveyor.
Remove the conveyor towards the front
side of the machine.
Adjust coffee grinding manually by rotating
the ring nuts:
● clockwise = ner grinding.
● Counterclockwise = coarser grinding.
NOTE
Rotate the ring nuts in small progressive
steps, checking the results from time to
time.
4.10.2 Grinder unit cleaning
Open the upper front door.
1
1
2
- -
++
Fixing aps
Coffee conveyor
Ring nuts
