3.4.6 Additional board 2nd group (Code 96.05292)
In the version “EF” (Espresso + Fresh Brew), the 2nd unit addi-
tional board powers the Fresh Brew unit.
Touchpad board (Item single code 96.05275)
3.4.7 Logo lighting board (Code 96.05353)
The logo lighting board powers the CARIMALI logo LED.
Utilities logic board
connection
From Fresh Brew unit
