Carimali BlueDot - Hydraulic Diagrams for Machine Versions

3.26
3.5 HYDRAULIC DIAGRAMS
3.5.1 Version Espresso + Instant products (E+1M)
9
8
16
6
4
3
7
12
11
15
14 13
2
1
5
10 10
17
N Components
1 Water stop solenoid valve 2 Air break 3 Vibration pump 4 4-way valve + VNR 5 Flowmeter 6 Coffee/instant product boiler
N Components
7
Espresso coffee 3-way sole- noid valve
8 Espresso unit 9
4-element, 2-way solenoid valve block
10 Mixer
N Components
11 Steam 3-way solenoid valve
12 Steam boiler 13 Milker steam solenoid valve 14
Milker rinsing water solenoid valve
N Components
15
Air 2-way solenoid valve block for milker/rinsing
16 Milk frother 17 Water tank
Milk Cold water Hot water Steam Air
