Carimali BlueDot - Wiring Diagram POWER out

3.24
3.4.11 Wiring diagram POWER OUT
2MMT 100 CLIXON
THERMOSTAT
RSV RCC
THERMOSTAT
DOOR MICROSWITCH
EARTH DISTRIBUTOR
MAINS INPUT 230V AC 10 A
IEC 320 C20 SOCKET WITH EMC FILTER
(DELTA 20GEEG3E)
MAIN BREAKER
10A FUSE
MACHINE
FAN
R1 OPTIONAL HEATING ELEMENT
M2GRINDER 2
GRINDER 1
VIBRATION PUMP
STEAM EXCHANGER HEATING ELEMENT
COFFEE BOILER HEATING ELEMENT
M1
R2 OPTIONAL HEATING ELEMENT
SOLUBLES FAN
24V dc
OUT
230V ac
IN
FEEDER
AROMA FAN
CUP
ELECTROMAGNET
AIR PUMP
DOSER 1 DOSER 2 MIXER 1 MIXER 2
WATER BY-PASS SOLENOID WATER INLET SOLENOID ESPRESSO GROUP SOLENOID HOT WATER WAND SOLENOID SOLUBLE 2 SOLENOID VALVE SOLUBLE 1 SOLENOID VALVE
MILKER AIR SOLENOID
COFFEE GROUP
MILKER RINSE WATER SOLENOID
SOLENOID FOR PRESSURISED
STEAM DISCHARGE/EXCHANGER
STEAM SOLENOID
MILKER RINSE AIR SOLENOID
SSR2
SSR2
+
-
+
-
+
-
+
-
F N
F N
F N
+
-
+
-
P1 ~ 1
+
-
+
-
FUSE CARRIER
