CO2/Temperature sensor
Carrier Sensors 33
Part #33ZCT55CO2
Part #33ZCT56CO2
A CO
2
/space temperature sensor houses two sensors in a single unit. This sensor uses Single Beam
Absorption Infrared™ diffusion technology to monitor carbon dioxide (CO
2
) levels and has a 10K thermistor to
measure space temperature. The controller uses this information to adjust the outside air dampers to provide
proper ventilation and control space temperature.
Sensor
Features
33ZCT55CO2
• CO
2
sensor
• Space temperature sensor
• Push-button override
33ZCT56CO2
• CO
2
sensor
• Space temperature sensor
• Push-button override
• Set point adjustment
NOTES
• The sensor has a 4–20 mA or 0–10 V output.
• Push button override
• Do not use a relative humidity sensor and CO
2
sensor on the same zone controller.
CO2/Temperature sensor
