Overview and specifications
Zone Ctrl II and
VAV Zone II Secondary Duct Installation and Start-up Guide CARRIER CORPORATION ©2019
Error! No text of specified style in document.
5 All rights reserved
VAV Zone II Secondary Duct specifications
Power requirements The VAV Zone II Secondary Duct receives power from the Zone Ctrl II. Increase the
controller's power supply by 3 VA when connecting a VAV Zone II Secondary Duct.
Actuator Belimo brushless DC motor, torque 45 inch-pounds (5 Nm), runtime 154 seconds
Act Net port To connect the actuator to the VAV Zone II Secondary Duct controller and to the
Zone Ctrl II
Protection Built-in surge and transient protection for power and communications in
compliance with EN61000-6-1.
Status indicators LEDs indicate status of communications, running, power, and motor direction
Environmental operating
range
32 to 130°F (0 to 54.4°C), 10–90% relative humidity, non-condensing
Integral airflow sensor Precision differential pressure sensor 0–2 in. H2O, sensitive down to ±0.001 in.
H2O. Barbed tapered airflow connections accept 3/16 in. (4.75 mm) I.D. tubing.
Allows for readings across the 0–2 in. H2O range, accurate to ±5% of full flow at 2
in. H2O.
Controller and actuator
overall dimensions
Width:
Height:
8.9 in. (22.7 cm)
5.9 in. (15.0 cm)
Controller and actuator
mounting dimensions
7.1 in. (18.0 cm) from left side controller mounting hole centerline to actuator
mounting hole centerline
Controller overall
dimensions
Width:
Height:
Depth:
6.4 in. (16.3 cm)
5.7 in. (14.5 cm)
2.1 in. (5.3 cm)
Controller mounting
dimensions
5.3 in. (13.4 cm) from left side controller mounting hole centerline to right side
controller mounting hole centerline
Actuator overall dimensions Width:
Height:
Depth:
3.0 in. (7.6 cm)
5.9 in. (15.0 cm)
2.5 in. (6.4 cm)
Actuator mounting 4.4 in. (11.2 cm) from shaft centerline to mounting hole centerline
Weight 1.8 lbs (0.82 kg)
Listed by UL-916 (PAZX), cUL-916 (PAZX7), FCC Part 15-Subpart B, Class B, CE
Disconnect electrical power to the Zone Ctrl II before wiring it. Failure to follow this warning could
cause electrical shock, personal injury, or damage to the controller.
