If a generator is being used, make sure:
• The generator is operating properly.
• The safety circuit breaker is ON, located on the generator control center.
If shore power is used, make sure:
• The shore power cord is properly attached to both the boat and the shore power source.
• The circuit breaker at the shore power source box is ON.
• The AC main circuit breaker group is ON.
If the voltmeter continues to read zero voltage, do one of the following:
• Have a qualied technician service your generator.
• Contact the marina’s management to identify and correct a shore power problem.
• If the problem appears to be with your boat’s AC electrical system, have the system inspected by a qualied electrician.
AMMETER – LOAD CURRENT
The ammeter indicates the amount of current being drawn by the AC electrical equipment.
The ammeter should read zero amps when the following items occur:
• Either the MAIN or GENERATOR circuit breaker group is ON and all other breakers on the AC control center are OFF.
• There is no power being consumed onboard the vessel.
The ammeter readings increase above zero amps:
• As the circuit breakers, located on the AC control center, are switched ON and the associated equipment is turned ON.
• As the equipment plugged into the AC receptacles is turned ON. See ELECTRICAL LOADS on page 57 for information on
the AC electrical system load limits.
AC CONTROL CENTER CIRCUIT BREAKERS
NOTE: A circuit breaker location may be labeled, but no circuit breaker is present. In this situation, the component
named on the label is an option that is not installed on the purchased model.
SHORE 2 CIRCUIT BREAKERS
AIR CONDITIONING WATER PUMP
NOTICE: Never switch the air conditioning system water pump breaker ON until after the seacock supplying the air
conditioning system with seawater has been opened. See Air Conditioning System on page 59 for more
information.
The air conditioning system water pump breaker controls the ow of electricity to the water pump that supplies the air
conditioning system with seawater. Switch the breaker ON to supply power to the water pump.
AIR CONDITIONING UNIT FORWARD STATEROOM (ONLY WITH HIGH-CAPACITY AIR CONDITIONING OPTION)
NOTICE: Never switch the air conditioning unit master stateroom breaker ON until after the seacock supplying the air
conditioning system with seawater has been opened. See Air Conditioning System on page 59 for more
information.
