SyStem Operating infOrmatiOnSyStem Operating infOrmatiOn
4327 • X5 04/2015 71
HULL DRAIN
CAUTION
SECURELY TIGHTEN THE DRAIN PLUG INTO THE HULL BEFORE LAUNCHING.
One hull drain is equipped on the yacht. The drain allows water to drain from the bilges while the yacht is in dry storage.
Make sure the yacht and cradle are positioned to allow water to ow toward the hull drain. The drain is located in the
transom in the deepest portion of the hull’s “V.”
The hull drain will drain water only from the bilge area AFT of the forward engine bulkhead. If water collects forward of the
engine room bulkhead, the water must be pumped out.
A TIP FROM CARVER!
Coat the threads of the hull drain plug with waterproof grease before you install the plug into the hull drain tting. This
makes it easier to remove the plug at a later date.
gray water system
The gray water system is designed to have the sinks and shower drain into the gray water sump that discharges the water
either overboard or into an onboard optional gray water tank.
GRAY WATER TANK (OPTIONAL)
Once the gray water tank is full, the tank can be emptied at dockside according to the procedure described in EMPTYING
THE WASTE TANK AND/OR OPTIONAL GRAY WATER TANK on page 72.
The gray water tank is located in the galley in oor storage compartment. When the gray water tank option exists, all sink
and shower water discharges into the gray water tank.
sanItatIon system
EASY FIT TOILETS
The toilet system uses a motor to ush the head. Instruct guests on how to properly use the system. Refer to the Original
Equipment Manufacturer (OEM) information for proper toilet usage. A single 70 gal (270 L) tank is supplied onboard.
