60 4327 • X5 04/2015
STANDARD
The standard air conditioning system consists of a single factory-installed 18,000 BTU air conditioning unit with ventilation
supplied to each room.
ACCESSING THE 18,000 BTU AIR CONDITIONING UNIT
1. Remove the galley hatch access door and proceed down the steps.
2. Remove the lower-level access panel on the STARBOARD side of the maintenance room to access the air
conditioning unit.
HIGH-CAPACITY
The high-capacity air conditioning system consists of three air conditioning units placed throughout the yacht with
ventilation supplied to each room. The air conditioning units and locations are as follows:
• MASTER STATEROOM:
A single 8,000 BTU unit is installed in the master stateroom within the frame of the bed.
• GALLEY:
Two 10,000 BTU units are installed below the galley hatch access door. Access is the same as the detail
previously shown.
Air
Conditioning
Unit
(8,000 BTU Unit)
PRODUCING HEAT
The air conditioning system produces heat when operated in reverse cycle mode. Reverse cycle operation is affected
by the temperature of the seawater. The air conditioning system’s ability to produce warm air decreases as seawater
temperature decreases. Carver recommends not operating the air conditioning system in reverse cycle mode when the
seawater temperature is below 40°F (4°C).
