CAS NT-302A - Serial I;F Mode Setting (under F33-00 Setting, Only); Serial Communication Speed Selection - Port No.1(Standard); Parity Bit Selection Mode - Port No.1(Standard); Communication Setting

25 / 44
Communication setting
Parity Bit selection Mode – Port No.1(Standard)
F30
●
0
No Parity
1
Odd Parity
2
Even Parity
Serial Communication Speed selection – Port No.1(Standard)
F31
0
115,200bps
1
76,800bps
2
57,600bps
3
38,400bps
4
28,800bps
5
19,200bps
6
14,400bps
●
7
9,600bps
8
4,800bps
9
2,400bps
Serial I/F Mode setting (Under F33-00 setting, only) – Port No.1(Standard)
F32
●
0
Steam Mode : Continuous Data transfer
1
Finish Mode : Single time data transfer, after Finish relay “ON”
- When Finish Relay output, Data will be output.
2
Print Mode : Single time data transfer, when print key input
Serial I/F Transference method setting – Port No.1(Standard)
F33
●
0
Simplex Mode
1
Duplex Mode / Command Mode
2
LCD Mode
ID No. setting
F34
01
01
∫
99
ID No. setting with No. key.
(01 ~99 settable)
