5. Command Mode
1. READ Command
PC  Indicator Format
Command
Response from Indicator
STX ID. NO. RTIM BCC ETX
Time Data
STX ID.NO. RTIM 000000
BCC ETX
STX ID. NO. RDAT BCC ETX
Date Data
STX ID. NO. RDAT 00000000
BCC ETX
STX ID. NO. RSNO BCC ETX
Serial No.
STX ID. NO. RSNO 000000
BCC ETX
STX ID. NO. RCNO BCC ETX
Code No.
STX ID. NO. RCNO 000000
BCC ETX
STX ID. NO. RPNO BCC ETX
Part No.
STX ID. NO. RPNO 00 BCC
ETX
STX ID. NO. RTAR BCC ETX
TARE weight value
STX ID. NO. RTAR 000000 BCC
ETX
STX ID. NO. RCWT BCC ETX
Current Weight value
STX ID. NO. RCWT DATA1 BCC
ETX
STX ID. NO. RSUB BCC ETX
Sub-Total Data
STX ID. NO. RSUB P/N(2)
CODE_BUF(6) COOUNT(6)
S.T.W(8) UNIT
BCC ETX
STX ID. NO. RGRD BCC ETX
Grand-Total Data
STX ID.NO. RGRD P/N(2)
CODE(6)
G.T.W(8) UNIT BCC ETX
STX ID. NO. RFIN BCC ETX
Weighing Condition
STX ID. NO. RFIN FN
(Finished weight 6byte) BCC
ETX
STX ID. NO. RFIN RN(Under
processing) BCC ETX
STX ID. NO. RCWD BCC ETX
Memorized Data
STX ID. NO. RCWD DATA2 BCC
ETX
STX ID. NO. RSP1 BCC ETX
SP1 DATA
- STX ID.NO. RSP1 000000
BCC ETX
STX ID. NO. RSP2 BCC ETX
SP2 DAT
- STX ID.NO. RSP2 000000
BCC ETX
STX ID. NO. RSP3 BCC ETX
SP3 DATA
- STX ID.NO. RSP3 000000
BCC ETX
STX ID. NO. RSP4 BCC ETX
SP4 DATA
- STX ID.NO. RSP4 000000
BCC ETX
Remarks
1. DATA 1
HEADE1 (2)
HEADE2 (2)
+/-, Weight value with Decimal point
(14)
UNIT (kg or t)(2)
