CAS NT-302A - Page 39

38 / 44
PC  Indicator Format
Command
Response from Indicator
STX ID. NO. WSTC BCC ETX
Sub-Total Data Clear
STX ID. NO. WSTC ACK BCC ETX
or
STX ID. NO. WSTC NAK BCC ETX
STX ID. NO. WGTC BCC ETX
Grand-Total Data Clear
STX ID. NO. WGTC ACK BCC ETX
or
STX ID. NO. WGTC NAK BCC ETX
STX ID. NO. WSTR BCC ETX
Start(Run) Input
STX ID. NO. WSTR ACK BCC ETX
or
STX ID. NO. WSTR NAK BCC ETX
STX ID. NO. WSTO BCC ETX
STOP Input
STX ID. NO. WSTO ACK BCC ETX
or
STX ID. NO. WSTO NAK BCC ETX
STX ID. NO. WSP1 SP1(6) BCC
ETX
ex) STX ID.NO WSP1 000000 BCC
ETX
SP1 set value change
STX ID. NO. WSP1 ACK BCC ETX
or
STX ID. NO. WSP1 NAK BCC ETX
STX ID. NO. WSP2 SP2(6) BCC
ETX
ex) STX ID.NO WSP2 000000 BCC
ETX
SP2 set value change
STX ID. NO. WSP2 ACK BCC ETX
or
STX ID. NO. WSP2 NAK BCC ETX
STX ID. NO. WSP3 SP3(6) BCC
ETX
ex) STX ID.NO WSP3 000000 BCC
ETX
SP3 set value change
STX ID. NO. WSP3 ACK BCC ETX
or
STX ID. NO. WSP3 NAK BCC ETX
STX ID. NO. WSP4 SP4(6) BCC
ETX
ex) STX ID.NO WSP4 000000 BCC
ETX
SP4 set value change
STX ID. NO. WSP4 ACK BCC ETX
or
STX ID. NO. WSP4 NAK BCC ETX
