6-MAINTENANCE
14.Turntheupperframe45°clockwise.Setthegatelock
levertocentralposition,stoptheengine,andremove
thestarterkey.
15.Repeattheproceduredescribedinthestepsfrom6to
14forthreemoretimes.
16.Completethecheckofthegreasingontheotherhalf
oftheswingring.Makesuretocheckthegreasing
every45°.
17.Installtheinspectioncover(2)onthefrontoftheupper
frame.
SMIL15CEX9587AA4
18.Getontothecab,starttheengine,andsetthegate
lockleverinforwardposition.Slowlyturntheupper
structureframecounterclockwise,andcompletethree
360°rotations.
19.Stoptherotation.Slowlyturntheupperstructure
frameclockwiseandcompletetwo360°rotations.
20.Stoptherotation.Setthegatelocklevertocentral
position,stoptheengine,andremovethestarterkey.
21.Cleanupanymoregreasethathascomeoutfromthe
sealinglipoftheturntablebearing.Makesurethatthe
sealinglipisresettoitsseatingposition.
22.Cleanthegreasettingsontheturntablebearing,and
installtheprotectivecaps.
23.Removetheplug(1)sotodrainanymorewaterand
greasymud.Tightentheplug(1).Installthecoverin
thebottomofthelowerframe.
SMIL14CEX4312AB5
6-40
