3-CONTROLSANDINSTRUMENTS

Mirrors

SMIL20CEX1391EB1

(A)Leftmirror—(B)Rightmirror—(C)Rightcounterweightmirror—(D)Rearcounterweightmirror

Installationandpositioningofthemirrors

WARNING

Avoidinjuryand/ormachinedamage!

Keepthemirrorscleanandproperlyadjusted.

Failuretocomplycouldresultindeathorseriousinjury.

W1078A

Theexternalmirrorsensurepropervisibilityaroundthe

machineduringoperation.

Thehatchedareasinthepicturesindicatethezonesthat

canbeviewedbyeachmirror.

SMIL20CEX1396BA2

3-52
