6-MAINTENANCE

5.Attachthedrainplug(4),andinstallthelowerpanel(3).

6.Supplyoilviathellport(2).

7.Attachtheoilgauge(1)andcheckthattheoillevelis

inthehatchedarea.

8.Waitfor10minandchecktheoillevelagain.Ifneces-

sary,supplyadditionaloilviathellport(2).

Attachthellplug(2).

SMIL15CEX9564AA4

6-56
