Case CX130C - Page 250

8-SPECIFICATIONS
CX130Cwithblade
SMIL20CEX1393FA3
Arm
2.10m(82.68in)2.50m(98.43in)3.00m(118.11in)
(A)2.71m(106.69in)2.81m(110.63in)2.82m(111.02in)
(B)7.61m(299.61in)7.62m(300.00in)7.64m(300.79in)
(C)2.43m(95.67in)
(D)(withoutgrousers)0.89m(35.04in)
(E)2.79m(109.84in)
(F)3.50m(137.80in)
(G)2.54m(100in)
(H)2.92m(114.96in)
(I)2.82m(111.02in)
(J)(withoutgrousers)0.42m(16.54in)
(K)(standardtrack)0.60m(23.62in)
(L)1.99m(78.35in)
(M)500mm(19.7in)pad2.49m(98.03in)
(M)600mm(23.6in)track2.59m(101.97in)
(M)700mm(27.6in)track2.69m(105.91in)
(N)0.57m(22.44in)
Boomlength:4.63m(182.28in)
NOTICE:forthe3.01m(118.50in)arm,thedimension(A)andthedimension(B)ofthereferencepositionshownin
gurearemeasuredwiththearmcylinderpinintransportposition.
8-8
