9-ACCESSORIES
Usageofahydrauliccrusher
1.Operatethecontrolsofboom,armandbucketinorder
toinstallthehydrauliccrushertothebucketlinkageat
thetopofthearm.
2.Stoptheengine.SetthestarterkeytoONposition,
andpresstheright-handauxiliarypedaltorelease
pressureinsidetheauxiliaryhigh-owhydrauliccircuit.
3.Closethefeedvalvesatthetopofthearm.Install
theconnectinghosesbetweentheattachmentandthe
feedvalves.Thenreopenthefeedvalves.
VOHLGR-0169
4.Starttheengine.Pressandholdtheattachmentse-
lectorbutton(1)for1stogetdirectlytothededicated
tabforoperationalsettingsoftheauxiliaryhigh-ow
hydrauliccircuit.
5.SelectCRUSHERasattachmenttype,andsetthe
properowrateofthecircuit.
NOTICE:Theworkingpressureofthemultifunction
auxiliaryhigh-owhydrauliccircuitshallbesetman-
uallybythereliefvalvelocatedbehindtheboomfoot.
6.Pressthemenubutton(2)toconrmtheselection.
SMIL18CEX0768AB10
7.Resumetheoperatingmodeofthedisplay.Anicon
onthetop-rightofthedisplayindicatesthetypeof
attachment(crusher)andthestoringnumber(1to5)
oftheowratecurrentlyinuse.
Thepumpsetting(singleortwin)andthevalueofmax-
imumowrateareshownatthetop-centerofthedis-
play.
NOTICE:topreventfailureordamagetothetool,
makesurethatyouselectthecorrectcircuitcongu-
rationandowrateandpressureforthetool.
SMIL18CEX0558AA11
Alternativedisplaylayoutincaseofrearviewcamerain-
stalled.
SMIL18CEX0559AA12
