Case CX145C SR - Page 163

4-OPERATINGINSTRUCTIONS
Tighteningtorqueofbolttotightthebodyofthemirror:
4.5-5.5N·m(3.3-4.1lbft).
F31B0E824
Ontheupperstructure(front)
Adjustthemirrortoseetherightfrontedgeofthemachine
bysight.
(L)dimension:310mm(12.2in).
200515AA5
Tighteningtorqueofbolttotightthebodyofthemirror:
4.5-5.5N·m(3.3-4.1lbft).
FB58285B6
Ontheupperstructure(rear)
Adjustthemirrortoseetherightrearedgeofthemachine
bysight.
(L)dimension:280mm(11.0in).
BE1F04E17
4-31
