Case CX145C SR - Page 164

4-OPERATINGINSTRUCTIONS
Tighteningtorqueofbolttotightthebodyofthemirror:
4.5-5.5N·m(3.3-4.1lbft).
E61A8D408
Onthecounterweight(left)
Adjustthemirrortoseetherearofthemachinebysight.
(L)dimension:455mm(17.9in).
4238E75D9
Tighteningtorqueofbolttotightthebodyofthemirror:
4.5-5.5N·m(3.3-4.1lbft).
8CD9301410
Onthecounterweight(right)
Adjustthemirrortoseetherearofthemachinebysight.
(L)dimension:40mm(1.6in).
818B6E9411
4-32
