Case CX145C SR - Page 70

3-CONTROLS/INSTRUMENTS
1.Enginecoolanttemperaturegauge
Displaysthetemperatureoftheenginecoolant.
Thelowerzoneindicatesthattheenginecoolanttem-
peratureislow.
Whenthetemperaturegaugedisplayreachestheup-
perzone,analarmsoundsand"Overheat"isdis-
played(see"Messagescreens").
Lowertheenginespeed.
Ifthetemperaturedoesnotgodown,stoptheengine,
removetheignitionkey,andinvestigatethecause.
2.Hydraulicoiltemperaturegauge
Displaysthetemperatureofthehydraulicoil.
Thelowerzoneindicatesthatthehydraulicoiltem-
peratureislow.
Whenthetemperaturegaugedisplayreachestheup-
perzone,analarmsoundsand"Overheat"isdis-
played(see"Messagescreens").
Lowertheenginespeed.
Ifthetemperaturedoesnotgodown,stoptheengine,
removetheignitionkey,andinvestigatethecause.
3.Fuelgauge
Displaystheremainingamountoffuelbythenumber
oflitsegments.
Whenallarelit,itindicatesthatthefueltankisfull.
Whenonly1islit,analarmsoundsand"Lowfuel"is
displayed(see"Messagescreens").
NOTE:Itisnotnecessarytowaituntilthefueltank
isemptybeforellingwithfuel.Ifthetankbecomes
empty,airbleedingofthefuelsystemisrequired.
4.Workmodeicon
Theseindicatorsdisplaytheinitialworkmodeand
theenginespeedthatwasselectedwiththeengine
accelerationbuttonandworkmodeselector.(Refer
topage3-58).
5.Travelmodeicon
Atlowspeed,isdisplayed.
Athighspeed,isdisplayed.
6.Workinglight
Displayedwhenthelightison.
7.Engineautoidlingandstopselectiondisplay
Displayedwhenautoidlingisselected.
“Auton/min”.
Displayedwhenautostopisselected.
“Autoidlestop”.
Displayedwhenautoidlingand
autostopareselected.“Auto
n/min”and“Autoidlestop”.
8.Freeswing,swingparkingandanti-theftprotection
Displayedwhenswingparkingisoperat-
ing(forserviceuseonly).
Displayedwhentheanti-theftprotection
functionisoperating.
Displayedwhenfreeswingisoperating.
9.Displaystheselectedattachment
Hydraulicbreaker
Crushergrapple
10.Clockdisplay
(Refertopage3-48).
11.Auxiliarysettingdisplay
Whenanoptioncircuitismounted,theselectedow
andpressurearedisplayed.
MUC8LU-043Z3
Icondisplay
Thesettingthatthewiper,idlingandglowswitches
areswitchedtoaredisplayedlargelyinthemiddleof
display.
•Wiperoperation
3-20
