3-CONTROLS/INSTRUMENTS
Displayedwhenthewiperoperationisswitched.
1stspeed
2ndspeed
Stop
•Idlemode
Displayedwhentheengineautoidlingandidlestop
operationsareswitched.
Autoidling
Autoidlestop
Autoidlingandidlestop
•Pre-heating(glowing)
12.Ecogauge
Thenumberofindicatorsonthisgaugeincreases
whentheoperatingstateisenergy-savingoperation.
Ifhigh-loadoperationsareperformed,thenumberof
gaugeindicatorsdecreases.
Thestateofenergy-savingoperationsisindicated.
•Nomechanicalabnormalitieswilloccurevenifthe
numberofgaugeindicatorsdecreases.However,to
helpconservetheenvironment,trytoperformen-
ergy-savingoperationswithinthegreenrange,so
longasdoingsodoesnothinderwork.
Keypointsforenergy-savingoperations
•TrytouseHmodeorAmodeinsteadofSPmode.
•Avoidsharpleveroperations.
•Avoidhighloadandreliefoperations.
•Useautoidleandone-touchidle.
Also,useidlestoptostopunnecessaryidling.
AskyourCASECONSTRUCTIONDealerabouthow
toturntheecogaugedisplay“On”and“Off”.
13.Autopressureboosticon
Displayedwhenthemaximumoutput
stateisenteredautomaticallyfortheat-
tachment.
14.Muteicon
Displayedwhentheradiovolumeis
muted.
15.Hourmeter
Thehourmeterdisplaystheengineoperationtimein
unitsof0.1hr.(6min.).
16.DPD(DieselParticulateDiffuser)gauge
IndicatesthestateoftheDPDlter.When5gauge
indicatorsarelit,DPDregenerationisperformed.
(Refertopage3-37).
17.DisplayduringDPD(DieselParticulateDiffuser)re-
generation
Duringautomaticregeneration:Green
Duringmanualregeneration:Yellow
Refertopage3-37fordetails.
18.FueleconomydisplayandDTC(DiagnosticTrouble
Code)display
Thetime/fuelconsumptionatthattime“gph”isdis-
played.
TheDTC(DiagnosticTroubleCode)isdisplayed
here.
19.Messagescreens
MUC8LU-042Z4
Thissectionofthedisplayscreenshowsinformation
iconsandmessagesthatchangeaccordingtotheset
applicationofthemachine.
Analarmalsosoundswhensomeofthesemessages
aredisplayed.
Thefollowingsectiondescribestheicons,mes-
sages,andtheircorrespondingexplanations.
NOTICE:Ifamessageisdisplayed,performmainte-
nanceaccordingtothemessage.
ATTENTION:Ifthemessageisstilldisplayedafter
maintenance,consultyourCASECONSTRUCTION
Dealer.
NOTE:Thelanguageofthedisplayedmessagescan
bechanged,consultyourCASECONSTRUCTION
Dealer.
•
Lowoilpressure
