Casio QT-6100 Service Manual

— 113 —
1 Standard Model USA
2 Standard Model Other
3 Dallas key Model
1 2 3
N Item Code No. Parts Name Specification
Price
Code
Rank
Q'ty
R7,12-18,23-27,
29,30,34,35,37,41,
43-48,54,62,64,
96,103,108,113,
135-174,183-192,
199,200,203-212,
224-234,237-239,
241,244,245,251,
253,254,257-260,
263,269-271,296,
298-308,311-313,
315-318,331,335
RESISTOR/CHIP WR06X103JTL 143 143 143 X
R252,276,278,
279,319,320
RESISTOR/CHIP WR06X104JTL 6 6 6 X
R33,333 RESISTOR/CHIP WR06X105JTL 2 2 2 X
R277 RESISTOR/CHIP WR06X113JTL 1 1 1 X
R95,101,106,
112,274
RESISTOR/CHIP WR06X123JTL 5 5 5 X
R69 RESISTOR/CHIP WR06X201JTL 1 1 1 X
R63,90 RESISTOR/CHIP WR06X203JTL 2 2 2 X
R39 RESISTOR/CHIP WR06X222JTL 1 1 1 X
R66,68,321,322 RESISTOR/CHIP WR06X24R9FTL 4 4 4 X
R56-61,67 RESISTOR/CHIP WR06X331JTL 7 7 7 X
R213,215,217,
220,222,223,
246,334,339
RESISTOR/CHIP WR06X470JTL 9 9 9 X
R38,91,114,123,
247,249,264,280,
281,282,287-289
RESISTOR/CHIP WR06X472JTL 13 13 13 X
R283,284 RESISTOR/CHIP WR06X49R9FTL 2 2 2 X
R9,10 RESISTOR/CHIP WR06X510JTL 2 2 2 X
R20-22,36,50,53,
72-76,84,89,94,98,
102,104,107,117,
122,131,132,134,175,
255,256,265-268,
272,273
RESISTOR/CHIP WR06X563JTL 36 36 36 X
R124 RESISTOR/CHIP WR06X6203FTL 1 1 1 X
R214,216,218,219,
235,236,337,338
RESISTOR/CHIP WR06X750JTL 8 8 8 X
R285,286,290,291 RESISTOR/CHIP WR06X75R0FTL 4 4 4 X
R336 RESISTOR/CHIP WR06X821JTL 1 1 1 X
R119 RESISTOR/CHIP WR06X822JTL 1 1 1 X
R125 RESISTOR/CHIP WR20X5R6JTL 1 1 1 X
RM6,7,9,12,38,46,
51,66,67,75,78,
79,82,85,88
REGISTOR ARRAY WA06X000PTL 15 15 15 X
RM1,3-5,8,10,11,
15,16,23,28,50,
52-59,61,80,83,
86,90,92
REGISTOR ARRAY WA06X103JTL 26 26 26 X
