Casio QT-6100 Service Manual

— 122 —
DL-2425(M type)
1
CASE/MAIN
RJE500529-001
1
NOT SUPPLY
X
N
1012 0508
PLATE/BOTTOM
RJE500534-001
1
X
N
2
1012 0509
CHASSIS/LEFT
RJE500532-001
1
X
N
3
1012 0510
CHASSIS/RIGHT
RJE500533-001
1
X
N
4
1012 0511
COVER/TOP
E240850-4
1
C
N
5
1012 0523
CHASSIS/BOTTOM
RJE500531-001
1
X
N
6
1012 0528
LOCK SUB ASSY
RJE500538*001
1
C
7
6246 5010
SPRING/PRESS
E412069-1
1
AA
X
N
8
1012 0529
PLATE/SPRING ED20
RJE500536-001
1
X
1008 0393
SPRING/LOCK
RJE500007-001
1
AA
C
SCREW
4X8 ZMC-3
3
X
N
9
1008 7972
SOLENOID SUB ASSY
RJE500128*003
1
B
N
1008 0964
SWITCH/MICRO
VX-013-1A3
1
B
SCREW
3X14 ZMC-3
2
X
TIE/INSULICK
T-18S
1
X
10
5500 0619
ROLLER/DELRIN
DR-19B1
2
AG
B
NUT/HEX
6 ZMC-3
2
X
WASHER
6X13X1.0 ZMC-3
2
X
11
1008 0450
RUBBER/DUMPER
RJE500005-001
4
AB
X
SCREW
4X5 ZMC-3
3
X
12
1007 8903
DRAWER SUB ASSY
E341274*1
1
BJ
X
13
5500 0619
ROLLER/DELRIN
DR-19B1
2
AG
B
14
5200 0106
RIVET
5X30
1
AA
X
15
6246 5030
SPRING/EARTH
E412092-1
1
AA
X
16
1007 9060
LOCK/CYLINDER
CL-16
1
BA
C
N
17
1012 1046
PANEL/FRONT
RJE500530-001
1
X
SCREW
3X10 NI
2
X
5440 0399
WASHER
6X13X1.0 ZMC-3
2
AA
X
18
1007 8757
CASE/BILL
E140505-1
1
AT
C
N
19
1010 6267
CASE/COIN
RJE500284-1
1
AH
C
N
20
1011 0335
PLATE/COIN CASE PARTITION
RJE500285-1
4
AA
B
21
1010 6268
PLATE/BILL CASE PARTITION
RJE500219-001
4
AA
B
22
1007 9062
BILL HOLDER SUB ASSY
E341290*1
5
AE
B
23
1007 9063
SPRING/BILL HOLDER
E441357-1
5
AA
C
24
1007 9064
BRACKET/BILL HOLDER
E240845-1
1
AD
X
SCREW
3X8 ZMC-3
3
X
SCREW
3X5 NI
5
X
SCREW
3X6 ZMC-3
15
X
N
25
1008 6054
FG CABLE SUB ASSY
RJE500104*001
1
X
SCREW
3X6 ZMC-3
3
X
WASHER
4
1
X
LABEL/DL-2425
E341256-33
1
X
N
26
1012 5287
CASE/RUBBER
RJE500667-001
4
C
27
6246 6529
RUBBER/PAD
E412136-1
4
AD
C
SCREW
4X8 ZMC-3
4
X
N
1013 1033
PLATE/FIX
RJE500775-001
2
X
Specification Qt'y Rank
Price
code
N Item Code No. Parts Name

Casio QT-6100 Specifications

General

Brand	Casio
Model	QT-6100
Category	Cash Register
Language	English
