— 112 —

1 Standard Model USA

2 Standard Model Other

3 Dallas key Model

1 2 3

1. MAIN PCB BLOCK

10315646 PCB ASSY/E819-1 RJE502692*001V01 1 1 1 ET A

IC45 LSI SM712GX04LF02-BA 1 1 1 X

IC40 LSI IDT2305A-1DCG 1 1 1 X

IC28 LSI LAN91C113-NU 1 1 1 X

IC26 10164750 LSI HD6417751RF240 1 1 1 CT B

IC14 10205905 LSI UPD65945GJP16-JEUA 1 1 1 BU B

IC44 LSI D784215AGC2728EUA 1 1 1 X

IC12 LSI HY5V52ALFP-H-C 1 1 1 X

IC1 LSI 29PL127J60TFI13004 1 1 1 X

IC2 10074003 IC XC6365A363MR 1 1 1 AG C

IC42 10166798 IC XC62EP1502MR 1 1 1 AK C

IC46 10165673 IC XC6219B332MR 1 1 1 AB C

IC34 10166799 IC XC6206P182MR 1 1 1 AG C

IC3,IC9,

IC23,IC27

10166792 IC HIN211CAZ-T 4 4 4 BH C

IC24 10166793 IC HIN202CBNZ-T 1 1 1 AV C

IC41 IC SG82JFSCB14.318MLF 1 1 1 X

IC43 IC SG-8002JFSCB33M-LF 1 1 1 X

IC19 IC RTC-7301DG-LF 1 1 1 X

IC6,IC7 10105408 IC/CMOS SN74LVC245APWR 2 2 2 AA C

IC4,IC5 10105407 IC/CMOS SN74LVC244APWR 2 2 2 AA C

IC11 10166801 IC/CMOS SN74LVC138APWR 1 1 1 AE C

IC25 10004414 IC/CMOS SN74LV74APWR 1 1 1 AC C

IC16,IC21,

IC50,IC51

10005662 IC/CMOS SN74LV374APWR 4 4 4 AF C

IC48,IC52-54 10004413 IC/CMOS SN74LV32APWR 4 4 4 AB C

IC22,IC38,IC39 10005721 IC/CMOS SN74LV244APWR 3 3 3 AF C

IC30 10007179 IC/CMOS SN74LV10APWR 1 1 1 AC C

IC47,IC57 10005659 IC/CMOS SN74LV08APWR 2 2 2 AB C

IC37 10105417 IC/CMOS SN74LV07APWR 1 1 1 AA C

IC10 10120129 IC/CMOS SN74LV04APWR 1 1 1 AC C

IC29 10003984 IC/CMOS SN74LV00APWR 1 1 1 AB C

IC32 10166802 IC/CMOS SN74HC148NSR 1 1 1 BD C

IC8 10166803 IC/CMOS SN74ALVCH16245DGGR 1 1 1 BF C

IC13,IC17 10166804 IC/CMOS SN74ALVCH16244DGGR 2 2 2 BF C

IC20 10166805 IC/CMOS SN74ALVC08PWR 1 1 1 AH C

IC49 10105416 IC/CMOS SN74AHCT08PWR 1 1 1 AC C

IC58,IC59 10147316 IC/CMOS SN74LVC1G97DCK3 2 2 2 AB C

IC56 10183834 IC/CMOS SN74LVC1G08DCK3 1 1 1 AD C

IC55 IC/RESET S-80828CLNB-B6NT2G 1 1 1 X

IC33 IC/RESET M51957BFP-CF1J 1 1 1 X

IC35 10166794 EEPROM BR93L46RF-WE2 1 1 1 AM C

R65,70,77-83,

85-87,92,93,97,

99,100,105,109,

110,115,121,

127,294,295

RESISTOR/CHIP WR06X000PTL 25 25 25 X

R118,129,130,

133,340-349

RESISTOR/CHIP WR06X101JTL 14 14 14 X

R1,11,40,120,128,

240,250,275,314

RESISTOR/CHIP WR06X102JTL 9 9 9 X
