1 Standard Model USA
2 Standard Model Other
3 Dallas key Model
1 2 3
N Item Code No. Parts Name Specification
Price
Code
Rank
Q'ty
N
16 10165823 COVER/DP SW E820 RJE501090-001V01 1
1 1
AK C
N
17 10165824 SEAL/MCR E820 RJE501106-001V01 1
1 1
BO C
N
18 10165825 CHASSIS/LR E820 RJE501108-001V01 1
1 1
BC C
N
19 10165826 CHASSIS/B E-820 RJE501109-001V01 1
1 1
BL C
N
20 10165827 CHASSIS/CON E820 RJE501111-001V01 1
1 1
AM C
N
21 10165828 CHASSIS/SW E820 RJE501114-001V01 1
1 1
AF C
N 22 10165829
CHASSIS/T E820
RJE501115-001V01 1 1 1 AT C
SCREW/WASHER PT S-WBPT-3X6ZC 6 6 5 X
N 23 10165833 IBUTTON ASSY RJE501183*001V01 1 DS C
N 24 10166867
SWITCH/POWER
SDDJE10700 1 1 1 AV C
N 25 10165835
CABLE SUB ASSY/S1
RJE501162*001V01 1 1 1 AJ C
N 26 10165836
CABLE SUB ASSY/CNB
RJE501165*001V01 1 1 1 AD C
N 27 10165837
CABLE SUB ASSY/MIC
RJE501166*001V01 1 1 1 AD C
N 28 10172645
BATTERY/NIH
HHR-21HL3G1C 1 1 CS A
N 28 10172644
BATTERY/NIH
HHR-21HL3G1B 1 CS A
TIE/CABLE
BK-1 2 2 2 X
N 29 10165839
CABLE SUB ASSY/CNB
RJE501165*002V01 1 1 1 AI C
N 30 10165841
CABLE SUB ASSY/MIC
RJE501166*002V01 1 1 1 AD C
N 31 10165842
CHASSIS/F E820
RJE501110-001V01 1 1 1 AU C
N 32 10170488
JOINER/FFC A-E820
RJE501228-001V01 1 1 1 AM C
33 10085156
CABLE SUB ASSY/DRAWER
E440737*1 1 1 1 AK C
FERRITE CORE
TR-20-10-10 1 X
4. REAR CASE BLOCK
N 34 10170482
CASE SUB ASSY/REAR
RJE501227*001 1 1 1 DB C
5. POWER SUPPLY PCB BLOCK
N 35 10315647 PCB ASSY/E819-S1 RJE502693*001V01 1 1 1 DK A
IC1 IC LM2678SX-ADJ/MOPB 1 1 1 X
R1 RESISTOR/CHIP WR06X1001FTL 1 1 1 X
R11 RESISTOR/CHIP WR06X100JTL 1 1 1 X
R12 RESISTOR/CHIP WR06X103JTL 1 1 1 X
R4,5 RESISTOR/CHIP WR06X202JTL 2 2 2 X
R2 RESISTOR/CHIP WR06X3481FTL 1 1 1 X
R6,7 RESISTOR/CHIP WR06X472JTL 2 2 2 X
C8,9 CAPACITOR/CHIP CERA 1206B474K500CT 2 2 2 X
C5 CAPACITOR/CHIP CERA 0603B333K500CT 1 1 1 X
C10 CAPACITOR/CHIP CERA 0603N102J500LT 1 1 1 X
C6,7 CAPACITOR/ALE 10SEP270M 2 2 2 X
C4 OS-CON/CHIP 35SVPD22M 1 1 1 X
C11,12 CAPACITOR/AL RJF-35V102MI6# 2 2 2 X
C1 CAPACITOR/CHIP AL RV-35V101MG10U-R 1 1 1 X
Q4 TRANSISTOR/CHIP DIGITAL DTC114YETL 1 1 1 X
Q2,3 TRANSISTOR/CHIP 2SD1626-TD-E 2 2 2 X
L1 INDUCTOR/CHIP CDRH127/LDNP-180MC 1 1 1 X
L2 BEADS/CHIP FBMH4532HM132-T 1 1 1 X
FU1 30007777 FUSE 0230.600MXP 1 1 1 AE A
D1,2 DIODE/CHIP DE10S3L-7061 2 2 2 X
