Casio QT-6100 Service Manual

— 2 —
1-5. I/O Ports
COM port (D sub 9pin) x 3
LAN port (Ethernet 10BASE-T/100BASE-TX) x 1
CF CARD slot x 1
Drawer port x 2
• LCD Display Name NL8060BC31-27
Size 12.1 inch SVGA TFT panel
Resolution 800 x 600
Interface CMOS 6 bits
Colors 262,144 colors
• Touch Panel Name N010-0550-T711
Size 12.1 inch
• Panel brightness control 1 x VR controller
• Power supply External adaptor "ADP820AA"
• Cleck key Magnetic ibutton prove "94-J-04"
1-4. Devices specifications
DC IN
PC/MODEM SCANNER D
IS
P
LA
Y
DR
W
1
DR
W2
COM1 COM3COM2
LA
N
1
COM1 COM2 COM3
From the AC adaptor
Inline (10/100Base-T)
Drawer 2
Drawer 1
Card slot cover
CF CARD slot
