— 44 —
[ 23 ] Buzzer test
[Function]
This test will check the buzzer function.
Ring the one-shot buzzer.
[Operation]
Operation : n 0 9 2 ST
n: 0 = One time check (can be omitted)
not 0 = Continuous check (To stop the test, press "ESC" key)
[LCD]
[PRINT]
[ 24 ] OBR test
[Function]
This is a scanner test. The test enters the wait mode for the scanner input, and waits only for
scanner.
The test determines the result between OK and NG by comparing the fixed data and the read
data.
Make sure to connect OBR (HHS-15) to COM 2.
* The fixed barcode is as follows.
[Operation]
Operation : 9 5 ST
To stop the test, press "ESC" key.
[LCD] [PRINT]
OBR 95
OBR O
K
OBR ERR xxxxxxxxxxxxxx
END
95
OBR 95
OBR O
K
OBR ERR xxxxxxxxxxxxxx
END
95
To Next Page
