— 45 —
[ 25 ] MCR test
[Function]
This is a card reader (MCR) test. The test enters the wait mode for only MCR input.
The test judges the result between OK and NG by the comparison between already set data
and read data.
[Operation]
Operation : 9 6 ST
Press [ESC] key to end the test manually.
[LCD]
MCR1 indicates track 1 while MCR2 indicates track 2 in the display.
* Normally ended (both track 1 and 2)
MCR 96
MCR1 O
K
MCR2 O
K
END
96
MCR2 ERR **************************
**************
MCR1 ERR **************************
******************************
MCR 96
MCR1 O
K
MCR2 OK
END
96
OK when the read data is correct.
* Error example
• The display shows error when the track 1 has an error.
The read data is displayed.
• The track 1 ended normally. Only the track 2 has an error.
Only the data read in the track 2 is displayed.
[PRINT]
