CASTLE S SERIES CONTROLLER – TECHNICAL OPERATION GUIDE
m. Local PIN 2 TimeZone
Set the TimeZone for the Local PIN 2, so that the Local Auto-PIN 2 can be used within the
TimeZone setting.
Example setting of Auto PIN Mode: -
PIN
MODE
USE
COMMON
COMMON
PIN (CP)
LOCAL
PIN (LP)
STATUS
ON YES Use CP (Tz) N/A CP activated with Tz
ON OFF N/A Local Pin LP activated
OFF YES N/A N/A Both deactivated
OFF NO N/A Local Pin (Tz) LP activated with Tz
n. Security
‘ON/OFF’ value. This option is used to enable or disable the security of the system.
When the Security Mode is ON, the reader will prompt the user for the Card, Card + PIN or
Auto-PIN to access the system; if the Security Mode is OFF, the electric lock will be released
and the door is always opened until the Security Mode is set to ON again.
o. PIN Mode
‘ON/OFF’ value. When the PIN Mode is set to ON, the user has to key in the Auto-PIN to access
the door; if it is set to OFF, the user will not be prompted to key in the Auto-PIN, but the user
can swipe his/her card to access the door.
p. Card + PIN Mode
‘ON/OFF’ value. When the Card + PIN Mode is set to ON, the user has to key in the Card PIN
after his/her card is valid. If it is set to OFF, depends on Card + PIN Mode TimeZone setting,
the user will not be prompted to key in the Card PIN, only swipe a valid card.
q. Master PIN
6 digits of number are required to set the MASTER PIN. This is used to enter the Programming
Mode at the reader when the controller is down. User can use this PIN number to program the
reader. (The programming steps are shown in Chapter 11)
CASS TECHNOLOGY SDN BHD(338857-X) 19
dd/mm DDD hh:mm:ss
Local Pin 2 Tz [00]
dd/mm DDD hh:mm:ss
Security [ON]
dd/mm DDD hh:mm:ss
Local Pin Mode [ON]
dd/mm DDD hh:mm:ss
Card + Pin Mode [ON]
dd/mm DDD hh:mm:ss
Master [000000]
