USER MANUAL
CS969
18
Once the machine is installed, remove the protection.
Handling from the front
Safety distance = 50 mm
Wooden block 120 x 150 x 850 mm
Fork of the lifting equipment
Handling from the side
Wooden block120 x 150 x 1200 mm
Fork of the lifting equipment
Safety distance = 50 mm
Figure 5-8
