5.6 Certifications
• ZKA TA7.1 as attended and unattended payment terminal
• EMV Level 1 and Level 2
• PCI-PTS 3.0 (with the SCR-B PCI 3.x)
• DC-POS 2.5 (also with DC-POS 2.4)
5.7 General technical information
5.7.1 Interfaces for vending machines and ECR
The ECR connection can be established via the LAN, MDB (optional in preparation) or RS232
interface.
• RS232 interface: Maximum transmission speed up to 115.200 Baud and Hardware-
Handshake are possible.
• LAN: Ethernet 10Base-T und 100Base-T, full duplex.
• MDB (Multi-Drop-Bus): 9600 Baud interface format for vending machines.
The serial protocol ZVT-ECR interface will mostly be used. The advantage of ZVT-ECR
interface that it is supported by almost all automated systems.
Die O.P.I. Interface is can also be used for vending and ticketing machines.
The OPP-C60 is ready to be used with the MDB interface.
The terminals have the special advantage, that the connection to a machine (e.g. vending
machine) can be used with different interface transmission speeds (19.200, 38.400, 115.200
Baud).
5.7.2 Keyboard OPP-C60s/m
The PIN pad of the OPP-C60s / m is equipped with a vandal
proof, high quality stainless steel keyboard with 20 keys, 4 of soft
keys (F1 - F4). The keys are equipped with tactile and audible
feedback by sound and embossing according to the specification
“EBS100V3 – October 2004” of ECBS.
