6.4.1.21 LED indicators at SCR-C
Function
Terminal
type
Condition
LED Indicators
ZVT Abort 06 B0
Fuel vending
Reader ready
Only yellow LED
ZVT status
request 05 01
Fuel vending
Reader ready
Only yellow LED
ZVT activate card
reader 08 50
Fuel vending
Activate command KL (Bitmap FA not
exists or FA=00)
Only green LED
ZVT activate card
reader 08 50
Fuel vending
Deactivate command KL (Bitmap FA
exists and content not 00)
Only yellow LED
ZVT read card 06
C0
Fuel vending
No
At beginning only
green LED, after
reading card,
Abort or Timeout
only yellow LED
Startup OPP
Fuel vending
No
Only yellow LED
Idle mode
All
“Ready info at customer display” active;
terminal ready (no terminal locks, keys
loader and initialization has been
executed)
Only green LED
Idle mode
All
“Ready info at customer display” active;
terminal not ready (terminal locked, no
keys loaded or initialization against host
needed)
Only red LED
General remarks:
- “Ready info at customer display” is usually not active at fuel vending terminals
- The indicators at fuel vending terminals are based on the following customer ideas:
o Red LED = Device not ready
o Yellow LED = Device ready, but actually no card read
o Green LED = Device ready, customer should insert card
6.4.2 O.P.I.
The specification „PA77S001 – CCV O.P.I. Interface“ is used as basis of the implementation
from O.P.I. interface. It is available on request.
