5.7.13 Interfaces
For several purposes the OPP-C60 has various interfaces that can be used.
The terminals have following interfaces for connecting external hardware:
• 4 RS-232 Ports:
1. POS: Connection between terminals and vending machine or ECR.
2. SCR: Connection between terminals and Secure Card Reader (SCR)
3. COM: Connection to contactless reader (e.g. COR)
4. MDB: (Multi-Drop-Bus): prepared for connection of vending machines with
MDB-Protocol. Also includes a normal serial port (COM2).
• LAN-Interface: Ethernet, 10/100MBit, Auto MDIX.
Communication protocol TCP/IP (more available on request) e.g. for Service-PC or
Host connection.
• USB 2.0 OTG (High Speed 480MBit/s and Full Speed 12MBit/s) for Host and device
connectivity (exp. Updates and. Configuration). USB Mini-B.
• USB 2.0 Host (Full Speed 12MBit/s connection e.g. of USB-to-ISDN Modules or
other connections. USB-A Port.
Note: For more information about the interfaces and their pin assignments, please refer
to chapter 6 of this.
5.7.14 Protocols
The following protocols are available with OPM-C60 and OPP C60 standard:
a) Interface protocols
• ZVT ECR Protocol
• O.P.I. (for Vending- and Ticketing machine)
• MDB (Multiple Drop Bus)
• Protocol for Terminal-Supervisor 3 und TKS
• TCP/IP
b) Host Protocols
• Poseidon
• Lavego
• CCV Pay
5.7.15 Software
The terminals are using a Linux operating system with the new SECpos EVO software from
our company.
